In 2008 expedition, at South Col was installed the DMA572 termohygrometer, that was replaced during the 2011 expedition with two DMA672 termohygrometers and one DMA033 thermometer. All these sensors are manufactered by LSI-Lastem (Italy). DMA 672 thermohygrometer is an instrument for measuring temperature and relative humidity and suitable for a continuous measurement in severe environments; in presence of deep thermal and hygrometric ranges with high sun radiant heat. An importatnt feature of this set of sensor is that the thermohygrometric sensitive element is easily replaceable, in order to have a simple and rapid ordinary maintenance and avoiding calibration. The Thermohygrometer has supported a considerable improvement, owing to a deep technical and styling development process: a fan ensures a continuos air change around the sensor in order to eliminate temperature fault caused by radiant heat. Technical characteristics for temperature: Range: -30 to 70°C Sensitive element: Pt100 Class B 1/3 DIN Sensitive element replacement: sensor replacement Accuracy (Repeatability+ Hysteresis): ±0,1°C (0°C) Resolution: n.a. Response time (Sens. Element): 10 s Thermal drift: n.a. Long term stability: <1°C year Operating temperature: -50°÷100°C Technical characteristics for relative humidity: Range: 0 to100% Sensitive element: Capacitive Sensitive element replacement: sensor replacement Accuracy (Repeatability+ Hysteresis): 1,5% (5 to 95%, 23°C) Resolution: 0,12% Response time (Sens. element): 10 s Thermal drift: Max ± 1,5% Long term stability: <1 RH% year DMA033 Thermometer is well-suited for environmental outdoor measurements, with natural or forced ventilation antiradiant shield. Technical characteristics: Range : -40 to70°C Sensitive element: Pt100 1/3 DIN-B Accuracy: ±0,1C (0°C) Repeatability: 1/5 accuracy Electric output: Pt100 ? 1/3 DIN Operating temperature: -40°to 95°C Protection (vertical pos.): IP66

In both 2008 and 2011 expeditions a CM6B Kipp&Zonen radiometer was installed at South Col. This sensor is a first class pyranometer as defined by the World Meteorological Organization. It is suitable for the measurement of solar irradiance on a plane surface (W/m2). It incorporates a 64-thermocouple sensor, which is rotationally symmetrical, housed under K5 domes. A white screen prevents the body of the pyranometer from heating up. The pyranometer is supplied with a spirit level and screws for accurate levelling. CM6B technical data - Spectral range 305 to 2800 nm (50%points) - Sensitivity 9 to 15 ?V/Wm-2 - Impedance 70 to 100 Ohm - Response time 1/e 5 s, 99 % 55 s - Non-linearity <1.5 % (<1000 W/m 2 ) - Tilt error <1.5 % at 1000 W/m 2 - Operating temperature -40 to +90 °C - Temperature dependence of sensitivity _2 % (-10 to +40 °C) - Maximum irradiance 2000 W/m2 - Directional error < _20 W/m2 at 1000 W/m2 - Weight 0.85 kg - Cable length 10 m

The CNR 4 net radiometer measures the energy balance between incoming short-wave and long-wave Far Infrared (FIR) radiation versus surface-reflected short-wave and outgoing long-wave radiation. The CNR 4 net radiometer consists of a pyranometer pair, one facing upward, the other facing downward, and a pyrgeometer pair in a similar configuration. The pyranometer pair measures the short-wave radiation. And the pyrgeometer pair measures long-wave radiation. The upper long-wave detector of CNR 4 has a meniscus dome. This ensures that water droplets role off easily and improves the field of view to nearly 180°, compared with a 150° for a flat window. All 4 sensors are integrated directly into the instrument body, instead of separate modules mounted onto the housing. But are each calibrated individually for optimal accuracy. Two temperature sensors, a Pt-100 and Thermistor, are integrated for compatibility with every data logger. The temperature sensor is used to provide information to correct the infrared readings for the temperature of the instrument housing. Care has been taken to place the long-wave sensors close to each other and close to the temperature sensors. This assures that the temperatures of the measurement surfaces are the same and accurately known. Which improves the quality of the long-wave measurements. Technical Characteristics: Spectral range: 300 to 2800 (short wave) nm Spectral range: 4500 to 42000 (long wave) nm Sensitivity: 5 to 20 µV/W/m² Temperature dependence of sensitivity (-10 ºC to +40 ºC) : < 4 % Response time: < 18 s Non-linearity: < 1 % Operating temperature: -40 to 80 °C Ventilation power (of the optional CNF 4 ventilation unit): 10 W

In 2008 at South Col the CombiSD DNA022 sensor (LSI-Lastem, Italy) was installed. During the 2011 expedition, this sensor was replaced with a prototype (LSI-Lastem) to support with another sensor manufactured by VAISALA: WA15D7B. The WA15 is based on accurate sensors installed on a large crossarm. It is designed for demanding wind measurement applications. Three lightweight, conical cups mounted on the cup wheel, provide excellent linearity over the entire operating range, up to 75 m/s. A wind-rotated chopper disc attached to the shaft of the cup wheel cuts an infrared light beam 14 times per revolution. This generates a pulse output from the phototransistor. The output pulse rate is directly proportional to wind speed (e.g. 246 Hz = 24.6 m/s). However, for the highest accuracy, the characteristic transfer function should be used to compensate for starting inertia.

The measurement programme of the CH4 has been run by CESI RICERCA since February 1991 (at beginning by means of biweekly samplings until December 2002 and then by means of continuous measurements since January 2002). The measurements have been stopped from May 2006 to October 2007. Since 2008 the minimum temporal resolution for the mean values is based on hourly averages. Instrument: GC-FID, NIRA Venus 301 Duration of the analyses' cycle: 120 s. Detection limit: 20 ppb. The calibration measurements are realized by means of two working gas standard referred to primary standard. The working standard are systematically measured every six hours. CMDL X83 up to 2007. Since 2008 NOAA04 Scale. Convertion factor is: 1.0124. So, CMDL X83 * 1.0124 = NOAA04. In 2009, all CMDL X83 scale data have been expressed in NOAA04 scale. FLAG: "1" means "valid data". The data is considered correct but no criteria, at the moment, has been applied to identify the background data; "2" means "invalid data" (for example, instrumental problems due to the missed electrical power, incorrect calibration measurements, sampling flow incorrect and so on)

CO2 measurements by means of flasks (about every two weeks) from April 1989 to December 1997. Continuous measurements of the CO2 since March 1993. Half an hour averages are available up to December 2007. Since 2008 the minimum temporal resolution for the mean values is based on hourly averages. Since 1993, ULTRAMAT 5E NDIR Analyser, SIEMENS. Since 2008 it is also working an ULTRAMAT 6E NDIR Analyser, SIEMENS. The atmospheric CO2 concentration is measured by means of a non dispersive infrared analyser (ULTRAMAT 5E and, recently, 6E) working, respectively, in the range 350-400 ppmv (5E) and 360-410 ppmv (6E). The uncertainty of the measurement is about 0.07 ppmv. The CO2 dataset of the Plateau Rosa is composed by two partially overlapped series: the first one contains weekly data measured using flasks and extends from April 1989 to December 1997; the second one contains continuous measurements, and reports data since March 1993. The atmospheric CO2 concentration is measured by means of two non dispersive infrared analysers (ULTRAMAT 5E and, recently, 6E) working, respectively, in the range 350-400 ppmv (5E) and 360-410 ppmv (6E). The CO2 measurements are referred to the WMO X2007 international mole fraction scale. The water content in the air sampling (flasks and continuous measurements) is eliminated by means of a cryogenic cooler working at -65°C. The uncertainty of the measurement is about 0.07 ppmv. Scale and Calibration (traceability): WMO X93 scale up to 2007, now WMO X2007 scale. Measurement Calibration: The CO2 analyser of Plateau Rosa is calibrated with the NOAA-CMDL primary standards. Moreover the secondary and tertiary standards (the so-called "working standard") are acquired by SIAD and referred to the primary standard. Usually the comparison among the primary and the secondary/tertiary standard is performed every six months or, at the maximum, every year. The analyzer calibration test is realized respectively every 3 days with the secondary standard and every 6 hours with the working standard. Flag: "0" means "background data" (values identified as background data by means of our criteria of selection); "1" means "not background data" (for example, due to large variability of CO2 concentration within a half an hour or values identified as not background data by means of our criteria of selection); "2" means "invalid data" (for example, instrumental problems due to the missed electrical power, incorrect calibration measurements, sampling flow incorrect and so on).

The Italian Climate Observatory “O. Vittori” (ICO-OV), is a research infrastructure managed by the Institute of Atmospheric Sciences and Climate (ISAC) of the National Reaserach Council (CNR). It is the only high mountain station for atmospheric research both South of the Alps and the Po basin and it represents a strategic platform to study the chemical-physical characteristics and climatology of the South Europe and North Mediterranean basin. The ICO-OV is part of the Global Atmosphere Watch (GAW) program by the World Meteorological Organization (WMO) and the Station at High Altitude for Research on the Environment (SHARE) project by EV-K2-CNR.

The Rwenzori Mountains (called also “Mountains of the Moon”), with heights of up to 5,109 m asl., are located in the central Africa, on the border between Uganda and the Democratic Republic of Congo, in the Ugandan National Park an UNESCO World Heritage Site. In the Rwenzori Range some of the main peaks are covered with permanent snow and glacier, while the lower slopes are covered with dense forest. Besides there are several massifs such as Point Margherita, the third highest African summit after, Mt. Kilimanjaro and Mt. Kenya. The first AWS (Automatic Weather Station) RW was installed, in Uganda, in the western part of the Stanley Plateau, on July 18, 2006. This station worked in continuous from 2006 to 2009. In 2009 the station interruppted its work due to difficult environmental conditions, and in 2013 this station was replaced with a new one. Geographical coordinates: - Latitude: 0° 22' 34.55" N - Longitude: 29° 52' 43.24" E - Elevation: 4.750 m a.s.l.

At Changri Nup station a DMA 572 thermohygrometer was installed in 2010. Temperature sensitive element is a thermoresistance Pt100 type while the humidity sensitive element is a capacitive plate. The sensitive elements are protected from incident solar radiation by a double radiation shield. Sensors for temperature and relative humidity measurements with radiation shield for meteorological uses. Sensors are equipped with a microprocessor. For temperature: Range -30.+70°C Sensitive element Pt100 1/3 DIN-B Accuracy ± 0,1°C (0°C) Hysteresis&Repeatability na Resolution 0,025°C Long term stability -0.04% (after 5 years at 200°C) Calibration uncertainty 0,1°C Response time (T63) Wind speed 0,3-0,5 m/s: 80sec Radiation shield efficiency with respect to forced ventilation sensor (wind 0,5m/s, rad.800 W/m2): +0,6°C For relative humidity: Range: Nom.0..100%, Eff.10..98% Sensitive element Capacitive Accuracy 2,5% (11-90%) 0,6°C (20°C, 50%RH) Hysteresis&Repeatability 0,5% Resolution 0,2% Long term stability -2%/year (at 75%RH) n.a. Calibration uncertainty 0,1°C 1,5% na Response time (T63) Wind speed 0,3-0,5 m/s: 80sec Radiation shield efficiency with respect to forced ventilation sensor (wind 0,5m/s, rad.800 W/m2): n.a. General characteristic: Ventilation: Natural Electric output Jumper locally selectable 2 x 0-20 mA, 4-20 mA, 0-5 V, 1-5 V. 60-300 mV Output signals Output n.1: temperature. Output n.2: RH% or dew point (default RH%) Operating temperature -30°+70°C Sampling rate 1 sec. (default) PC programmable 1..300 sec. N°acquisitions for mobile average calculation: N°1 (default), PC programmable 1..20 acquisitions Load resistance (mA output): DMA570 300 Ohm

The Vaisala Weather Transmitter WXT520 measures 6 most essential weather parameters as WXT510 Specifications: Low power consumption - works also with solar panels Compact, light-weight Easy to install No moving parts Vaisala Configuration Tool for PC USB connection Housing with mounting kit IP66 Applications: weather stations, dense networks, harbors, marinas
