Both in 2008 and in 2011 expedition a CM6B Kipp&Zonen radiometer was installed at South Col. The radiometer measures the energy balance between incoming short-wave and long-wave IR radiation versus surface-reflected short-wave and outgoing long-wave IR radiation.
-
Solar radiation (wavelength: 350 – 1100 nm) is measured by a silicon cell pyranometer (Skye SKS110).
-
Wind speed and direction measurements are carried out by the Vaisala WS425 ultrasonic anemometer.
-
At the Pyramid Laboratory Observatory AWS the DMA570 Lsi-Lastem Thermohygrometer is mounted on a 2 m pole. It is a probe for measuring air temperature and air relative humidity with replaceable sensitive element for simplify calibration and maintenance. LSI-Lastem supplies a precise and reliable set of probes, suitable for a continuous measurement in severe environments, in presence of deep thermal and hygrometric ranges with high sun radiant heat. An important feature of this set of sensor is that the thermohygrometric sensitive element is easily replaceable, in order to have a simple and rapid ordinary maintenance and avoiding calibration. The Thermohygrometer has supported a considerable improvement, owing to a deep technical and styling development process: a fan ensures a continuos air change around the sensor in order to eliminate temperature fault caused by radiant heat. For temperature: Range -30.+70°C Sensitive element Pt100 1/3 DIN-B Accuracy ± 0,1°C (0°C) Hysteresis&Repeatability na Resolution 0,025°C Long term stability -0.04% (after 5 years at 200°C) Calibration uncertainty 0,1°C Response time (T63) Wind speed 0,3-0,5 m/s: 80sec Radiation shield efficiency with respect to forced ventilation sensor (wind 0,5m/s, rad.800 W/m2): +0,6°C For relative humidity: Range: Nom.0..100%, Eff.10..98% Sensitive element Capacitive Accuracy 2,5% (11-90%) 0,6°C (20°C, 50%RH) Hysteresis&Repeatability 0,5% Resolution 0,2% Long term stability -2%/year (at 75%RH) n.a. Calibration uncertainty 0,1°C 1,5% na Response time (T63) Wind speed 0,3-0,5 m/s: 80sec Radiation shield efficiency with respect to forced ventilation sensor (wind 0,5m/s, rad.800 W/m2): n.a. General characteristic: Ventilation: Natural Electric output Jumper locally selectable 2 x 0-20 mA, 4-20 mA, 0-5 V, 1-5 V. 60-300 mV Output signals Output n.1: temperature. Output n.2: RH% or dew point (default RH%) Operating temperature -30°+70°C Sampling rate 1 sec. (default) PC programmable 1..300 sec. N°acquisitions for mobile average calculation: N°1 (default), PC programmable 1..20 acquisitions Load resistance (mA output): DMA570 300 Ohm
-
The DNA022 Lsi-Lastem combined wind speed-direction sensor is mounted on a 5m pole on Changri Nup station. The CombiSD sensor includes, in a single apparatus, the both transducers for measuring wind speed and wind direction. Its use simplifies the installation and the plant design in respect of the sensors with separate measurements plus giving some other advantages being smaller, lighter and cheaper. The CombiSD DNA022: sensor has a direct signal output. Frequency (Hz) for wind speed and resistance (Ohm) for wind direction. The CombiSD has low power consumption, it can be used in systems with small energy availability.
-
Both in 2008 and in 2011 expedition a PTB330 barometer was installed at South Col. This sensor is manufactured by Vaisala company. Vaisala's Barometer measure Atmospheric Pressure in weather station.
-
At the Nepal Climate Observatory - Pyramid, aerosol total and back scattering coefficients at three wavelengths (450, 550 and 700 nm) are derived by an integrating nephelometer (model TSI 3563).
-
The DMA570 Lsi-Lastem Thermohygrometer is mounted on a 2 m pole. It is a probe for measuring air temperature and air relative humidity with replaceable sensitive element for simplify calibration and maintenance. LSI-Lastem supplies a precise and reliable set of probes, suitable for a continuous measurement in severe environments, in presence of deep thermal and hygrometric ranges with high sun radiant heat. An important feature of this set of sensor is that the thermohygrometric sensitive element is easily replaceable, in order to have a simple and rapid ordinary maintenance and avoiding calibration. The Thermohygrometer has supported a considerable improvement, owing to a deep technical and styling development process: a fan ensures a continuos air change around the sensor in order to eliminate temperature fault caused by radiant heat. Technical Characteristics: For temperature: Range -30.+70°C Sensitive element Pt100 1/3 DIN-B Accuracy ± 0,1°C (0°C) Hysteresis&Repeatability na Resolution 0,025°C Long term stability -0.04% (after 5 years at 200°C) Calibration uncertainty 0,1°C Response time (T63) Wind speed 0,3-0,5 m/s: 80sec Radiation shield efficiency with respect to forced ventilation sensor (wind 0,5m/s, rad.800 W/m2): +0,6°C For relative humidity: Range: Nom.0..100%, Eff.10..98% Sensitive element Capacitive Accuracy 2,5% (11-90%) 0,6°C (20°C, 50%RH) Hysteresis&Repeatability 0,5% Resolution 0,2% Long term stability -2%/year (at 75%RH) n.a. Calibration uncertainty 0,1°C 1,5% na Response time (T63) Wind speed 0,3-0,5 m/s: 80sec Radiation shield efficiency with respect to forced ventilation sensor (wind 0,5m/s, rad.800 W/m2): n.a. General characteristic: Ventilation: Natural Electric output Jumper locally selectable 2 x 0-20 mA, 4-20 mA, 0-5 V, 1-5 V. 60-300 mV Output signals Output n.1: temperature. Output n.2: RH% or dew point (default RH%) Operating temperature -30°+70°C Sampling rate 1 sec. (default) PC programmable 1..300 sec. N°acquisitions for mobile average calculation: N°1 (default), PC programmable 1..20 acquisitions Load resistance (mA output): DMA570 300 Ohm
-
At the AWS Urdukas station the CM6B Kipp&Zonen pyranometer is installed. It is mounted on a 2m pole. The CM6B is a first class pyranometer as defined by the World Meteorological Organization. It is suitable for the measurement of solar irradiance on a plane surface (W/m2). It incorporates a 64-thermocouple sensor, which is rotationally symmetrical, housed under K5 domes. A white screen prevents the body of the pyranometer from heating up. The pyranometer is supplied with a spirit level and screws for accurate levelling. A drying cartridge keeps the interior free from humidity. The technical characteristics are: - Spectral range 305...2800 nm (50%points) - Sensitivity 9...15µV/Wm-2 - Impedance 70...100 Ohm - Response time 1/e 5 s, 99 % 55 s - Non-linearity <1.5 % (<1000 W/m2) - Tilt error <1.5 % at 1000 W/m2 - Operating temperature -40...+90 °C - Temperature dependence of sensitivity +/- 2% (-10...+40°C) - Maximum irradiance 2000 W/m2 - Directional error <+/- 20 W/m2 at 1000 W/m2 - Weight 0.85 kg - Cable length 10
-
Global solar radiation (wavelength: 350 – 1100 nm) is measured by a silicon cell pyranometer (Skye SKS110).
