The DQA035 Lsi-Lastem rain gauge is mounted on a 1,5 m mast. This model of Rain gauge has a 1.000 cmq collector area. The measurement device is composed of a collector cone and a double chamber bascule connected to a magnete that operates one (optional two) reed switch, which generates impulses that can be counted by external meters: each impulse is equal to 0.2 mm of rain (optional from 0.1 to 0.5 mm). The mechanical and electrical specifications are: - Collector surface area: 1000 cmq - Collector area diameter: 420 mm - Measurements range: 180 mm/hr - Resolution: o,2 mm/imp. (opt. 0,1; 0,3; 0,4; 0,5; mm/imp.) - Accuracy: 0-1 mm/min: 1% 1-3 mm/min: 2% 3-5 mm/min: 4% 5-10 mm/min: 8% - Contact: 1 reed (opt. N.2 reed) 0,5 A/24V non inductive - Pulse duration: 100 msec.± 5 - Collector cone material: Brass - External housing material: Inox AISI30 - Tipping bucket material: Alluminium - Cable: 10 m - Weight: 6,3 kg - Power supply: /thermocover 100 W, 24 Vca/Va

At the AWS Askole station the DQA035 Lsi-Lastem rain gauge is mounted on a 1,5 m mast. This model of Rain gauge has a 1.000 cmq collector area. The measurement device is composed of a collector cone and a double chamber bascule connected to a magnete that operates one (optional two) reed switch, which generates impulses that can be counted by external meters: each impulse is equal to 0.2 mm of rain (optional from 0.1 to 0.5 mm). The mechanical and electrical specifications are: - Collector surface area: 1000 cmq - Collector area diameter: 420 mm - Measurements range: 180 mm/hr - Resolution: o,2 mm/imp. (opt. 0,1; 0,3; 0,4; 0,5; mm/imp.) - Accuracy: 0-1 mm/min: 1% 1-3 mm/min: 2% 3-5 mm/min: 4% 5-10 mm/min: 8% - Contact: 1 reed (opt. N.2 reed) 0,5 A/24V non inductive - Pulse duration: 100 msec.± 5 - Collector cone material: Brass - External housing material: Inox AISI30 - Tipping bucket material: Alluminium - Cable: 10 m - Weight: 6,3 kg - Power supply: /thermocover 100 W, 24 Vca/Va

At the AWS Kala Patthar station the DQA030 rain gauge is manufactured by LSI-Lastem equipped with a siphon placed on the cone's nozzle; it has two functions: during light rain the drizzle falls on the bascule without moving it and therefore evaporates without being measured; during heavy rain, it regulates the flow into the bascule permitting all the water to fall inside. LSI-LASTEM rain gauges have stainless steel housing whereas the cone has been designed to avoid the drops splash phenomena and to allow water droplets to dribble down inside even in case of very light rain. The rain gauge can be placed either directly on the ground by means of the DYA042 base plate or mounted on the top or the side of 50 mm diameter. For sites with sub-zero temperatures, the thermostatic heated models ensure the complete melting of snow, even at extreme temperature, whereas minimizing losse of evaporation; these models are insulated to reduce heat dispersion.

At the AWS Kala Patthar station the DQA030 rain gauge is manufactured by LSI-Lastem equipped with a siphon placed on the cone's nozzle; it has two functions: during light rain the drizzle falls on the bascule without moving it and therefore evaporates without being measured; during heavy rain, it regulates the flow into the bascule permitting all the water to fall inside. LSI-LASTEM rain gauges have stainless steel housing whereas the cone has been designed to avoid the drops splash phenomena and to allow water droplets to dribble down inside even in case of very light rain. The rain gauge can be placed either directly on the ground by means of the DYA042 base plate or mounted on the top or the side of 50 mm diameter. For sites with sub-zero temperatures, the thermostatic heated models ensure the complete melting of snow, even at extreme temperature, whereas minimizing losse of evaporation; these models are insulated to reduce heat dispersion.

This instrument uses a tipping-bucket mechanism to produce a contact closure every time it receives a predetermined small quantity of rainfall (0.2 mm). The body and funnel of the gauge are of aluminium alloy. An accurately machined septum-ring at the top gives an aperture of exactly 400 cm 2 . The tipping-bucket mechanism is mounted inside the body on a cast aluminium-alloy base equipped with fixing slots, three levelling screws and a spirit level. The mechanism consists of a divided bucket pivoted at its centre. Rain collects in the upper half. When this is full, the mechanism tilts and discharges the collected water, allowing the other half of the bucket to begin filling. A siphon device is fitted to the base of the funnel to control the rate of flow into the buckets. By ensuring a constant flow rate into the tipping bucket, calibration is made easier and accuracy improved. The alternate filling and discharging continue as long as rain is falling, and at each tilt, magnet momentarily closes the contacts of a reed switch. In the rain gauge of type RG13H, a heater element is provided inside the body in order to melt snow. The heater switches on at temperatures below +4 °C. Technical Specifications Diameter of aperture: 225 mm Area of aperture: 400 cm2 Rainfall capacity unlimited Sensitivity (rainfall per pulse) : 0.2 mm Dimensions (height diameter): 390 300 mm Weight: 2.5 kg Heater (in RG13H) : 38 W/40 VAC Thermostat operation: Open at +11 ºC (±3 ºC) Close at +4 ºC (±3 ºC)
