At the AWS Urdukas station the CM6B Kipp&Zonen pyranometer is installed. It is mounted on a 2m pole. The CM6B is a first class pyranometer as defined by the World Meteorological Organization. It is suitable for the measurement of solar irradiance on a plane surface (W/m2). It incorporates a 64-thermocouple sensor, which is rotationally symmetrical, housed under K5 domes. A white screen prevents the body of the pyranometer from heating up. The pyranometer is supplied with a spirit level and screws for accurate levelling. A drying cartridge keeps the interior free from humidity. The technical characteristics are: - Spectral range 305...2800 nm (50%points) - Sensitivity 9...15µV/Wm-2 - Impedance 70...100 Ohm - Response time 1/e 5 s, 99 % 55 s - Non-linearity <1.5 % (<1000 W/m2) - Tilt error <1.5 % at 1000 W/m2 - Operating temperature -40...+90 °C - Temperature dependence of sensitivity +/- 2% (-10...+40°C) - Maximum irradiance 2000 W/m2 - Directional error <+/- 20 W/m2 at 1000 W/m2 - Weight 0.85 kg - Cable length 10

At the AWS Pheriche station the CM6B Kipp&Zonen pyranometer is installed. It is mounted on a 2m pole. The CM6B is a first class pyranometer as defined by the World Meteorological Organization. It is suitable for the measurement of solar irradiance on a plane surface (W/m2). It incorporates a 64-thermocouple sensor, which is rotationally symmetrical, housed under K5 domes. A white screen prevents the body of the pyranometer from heating up. The pyranometer is supplied with a spirit level and screws for accurate levelling. A drying cartridge keeps the interior free from humidity. The technical characteristics are: - Spectral range: 305 to 2800 nm (50%points) - Sensitivity: 9 to 15µV/Wm-2 - Impedance: 70 to100 Ohm - Response time: 1/e 5 s, 99 % 55 s - Non-linearity: <1.5 % (<1000 W/m2) - Tilt error: <1.5 % at 1000 W/m2 - Operating temperature: -40 to +90 °C - Temperature dependence of sensitivity +/- 2% (-10 to +40°C) - Maximum irradiance 2000 W/m2 - Directional error: <+/- 20 W/m2 at 1000 W/m2 - Weight: 0.85 kg - Cable length: 10

At the Lukla station the the CM6B pyranometer, manufactured by Kipp & Zonen is installed. This sensor is a first class pyranometer as defined by the World Meteorological Organization. It is suitable for the measurement of solar irradiance on a plane surface (W/m2). It incorporates a 64-thermocouple sensor, which is rotationally symmetrical, housed under K5 domes. A white screen prevents the body of the pyranometer from heating up. The pyranometer is supplied with a spirit level and screws for accurate levelling. CM6B technical data - Spectral range 305 to 2800 nm (50%points) - Sensitivity 9 to 15 ?V/Wm-2 - Impedance 70 to 100 Ohm - Response time 1/e 5 s, 99 % 55 s - Non-linearity <1.5 % (<1000 W/m 2 ) - Tilt error <1.5 % at 1000 W/m 2 - Operating temperature -40 to +90 °C - Temperature dependence of sensitivity _2 % (-10 to +40 °C) - Maximum irradiance 2000 W/m2 - Directional error < _20 W/m2 at 1000 W/m2 - Weight 0.85 kg - Cable length 10 m

At the AWS Askole station the CM6B Kipp&Zonen pyranometer is installed. It is mounted on a 2m pole. The CM6B is a first class pyranometer as defined by the World Meteorological Organization. It is suitable for the measurement of solar irradiance on a plane surface (W/m2). It incorporates a 64-thermocouple sensor, which is rotationally symmetrical, housed under K5 domes. A white screen prevents the body of the pyranometer from heating up. The pyranometer is supplied with a spirit level and screws for accurate levelling. A drying cartridge keeps the interior free from humidity. The technical characteristics are: - Spectral range 305...2800 nm (50%points) - Sensitivity 9...15µV/Wm-2 - Impedance 70...100 Ohm - Response time 1/e 5 s, 99 % 55 s - Non-linearity <1.5 % (<1000 W/m2) - Tilt error <1.5 % at 1000 W/m2 - Operating temperature -40...+90 °C - Temperature dependence of sensitivity +/- 2% (-10...+40°C) - Maximum irradiance 2000 W/m2 - Directional error <+/- 20 W/m2 at 1000 W/m2 - Weight 0.85 kg - Cable length 10

The Pyramid station is equipped with sensor (CM6B Kipp&Zonen) for measuring Flux Parameter. It is suitable for the measurement of solar irradiance on a plane surface (W/m2).

The Pyramid station is equipped with sensor (CM6B Kipp&Zonen) for measuring Flux Parameter. In particolar the sensor measures the solar irradiance on a plane surface (W/m2).

At the Kala Patthar station the the CM6B pyranometer, manufactured by Kipp & Zonen is installed. This sensor is a first class pyranometer as defined by the World Meteorological Organization. It is suitable for the measurement of solar irradiance on a plane surface (W/m2). It incorporates a 64-thermocouple sensor, which is rotationally symmetrical, housed under K5 domes. A white screen prevents the body of the pyranometer from heating up. The pyranometer is supplied with a spirit level and screws for accurate levelling.

At the Kala Patthar station the the CM6B pyranometer, manufactured by Kipp & Zonen is installed. This sensor is a first class pyranometer as defined by the World Meteorological Organization. It is suitable for the measurement of solar irradiance on a plane surface (W/m2). It incorporates a 64-thermocouple sensor, which is rotationally symmetrical, housed under K5 domes. A white screen prevents the body of the pyranometer from heating up. The pyranometer is supplied with a spirit level and screws for accurate levelling.

Pheriche station is equipped with sensor for measuring global solar radiation. The sensor ( CM6B Pyranometer) takes hourly measurements of global radiation.
